Sauna control Premium eos Emotec d for dry Finnish saunas
the modern control unit from eos with a very flat control panel and a separate power section was created especially for the control of demanding private and commercial saunas. the TFT color display of the eos Emotec d with an innovative operating concept thanks to the rotary pushbutton switch convinces with a very fast and simple operation, which can be carried out in 18 menu languages. furthermore, the sauna control system has an extensive range of functions and a variety of expansion options, such as the control of colored light LEd systems, music, infrared and can optionally be operated via smartphone and tablet.
Convince yourself with the following official
presentation of the sauna control by eos:
Functions eos Emotec d
- Temperature control 30 °c - 115 °c.
- Menu navigation in 18 languages (dE, en, fr, ru, es, nl, it, pl, slo, fin, tr, cz, ro, bg, hu, hr, sk, dK).
- Quick function selection and setting with rotary pushbutton. Intuitive navigation with symbols and plain text indications.
- Installation possible up to 100 m from the sauna. Surface and flush mounting.
- Output for cabin light, dimmable, automatic detection of inductive and capacitive loads.
- Output for fan, adjustable.
- 24 hrs. time preselection or weekly timer (4 switching times/day).
- Heating time limit 6 hrs / 12 hrs / infinite.
- Screen saver and stand-by mode.
- Service and setup area with PIN code protection.
- Child lock and innovative ?holiday home" mode.
- Service level with numerous setting options.
- Floating output.
- Bank sensor optionally connectable.
- Remote start or remote control via optional modules.
- Color light control, audio control via optional modules.
- Control panel incl. housing for wall mounting and surface mounting, with 5 m connection cable (extendable up to 100 m).
- digital temperature sensor with 5 m cable.
- Firmware can be updated with a micro Sd card.
- Connection in the power section possible from the back and from the bottom.
- Switching capacity 9 kw, expandable with lsg devices.
Technical data eos Emotec d
Electrical connection |
400 v 3n ac 50 Hz |
Switching capacity |
9,0 kW (expandable with power switching devices) |
Output light |
230 v; resistive, capacitive, inductive load |
Output fan |
230 v / max. 150 w, adjustable |
Temperature sensor |
digital, with 5 m cable. Bench sensor optional |
Dimensions control panel HxWxD |
127 x 130 x 25 mm |
Dimensions load part HxWxD |
270 x 300 x 100 mm |
Models / variants |
94.5559 - Emotec d anthracite / silver 94.6053 - Emotec d white / silver 94.7256 - Emotec d anthracite / black |
Nachfolgend können Sie sich bequem das technische Datenblatt zur EOS Saunasteuerungen Emotec D herunterladen. Das Datenblatt von EOS enthält eine Anschluss-Übersicht, Informationen zur Montage des Bedien- und Leistungsteils und der Fühler, und klärt über optionales Zubehör und Erweiterungsmodule auf.
Download Technisches Datenblatt EOS Emotec D
