Fontan ice fountain - central wellness attraction
The Fire and Ice ice fountain Fontan is a ready-to-plug-in
(plug and play) Ice machine, which is controlled by means of a
Light barrier completely
independently with the ice - production begins or stops. The crushed ice can be used in the sauna for effective and fast distribution of oils and flavors of infusions (ice balls) and for the tingling and fast cooling of the heated skin after the sauna session very versatile. The water-cooled/air-cooled ice machine is made of a luxurious
Corian body which, due to the high-quality production in Germany and the special nature of the solid surface material, has a nearly
pore-free and impact-resistant surface which makes the ice fountain very
resilient and
easy to clean easy to clean. The tremendous
Stability of the round ice fountain is ensured by the construction of the corpus and the properties of the corian on all surfaces.
Due to the fountain-like production of the ice (the crushed ice is pushed upwards in a fountain and collected in the ice basin) and the
four visible sides the exclusive ice maker can be installed in any commercial wellness facility
centrally in the center of the sauna area as a technical and optical attraction. As a perfect companion for a refreshing cooling down after the sauna the Fire and Ice ice fountain Fontan is considered due to its very powerful - but almost
silent - Production of 300kg of ice per day, which uses the
environmentally friendly Refrigerant r452a is used
Functionality of the FireundIce ice fountain Fontan
Invisible and inaudible to the user, the ice machine ensures
automated a constantly filled ice basin. With the help of a pre-installed
Light barrier the ice fountain fills the large basin completely with the finest crushed ice (micro ice) thanks to the intelligent positioning of the light barrier. As soon as the ice basin is filled to the maximum, the machine stops the ice ejection. If ice is removed, the machine registers this and the ice fountain automatically starts producing fresh ice again.
Technical data of the Fontan ice maker:
Ice fountain for large wellness facilities (12.5kg/h) Fontan:
| Overall dimensions (DxH) |
80 x 130 cm |
| Basin dimensions |
110 x 20 cm |
| Weight |
approx. 150 kg |
Download technical drawing ice fountain Fontan
Corian body Fontan
Materialcorian, 19 mm
Color corpus: Glacier White (standard, entire Corian color palette applicable)
Download Corian - color palette "
Here for free 6x4cm Corian sample pieces request!Determine the appropriate machine size of the ice fountain
Generally, the required machine size depends on various key data, such as the desired purpose, your opening hours and
Number of guests. We would be happy to assist you personally in choosing the right ice machine, but in principle you can rely on the rule of thumb of
0,5-1 kg ice per guest and the following empirical values:
"For use in your
private sauna facility we recommend the ice fountain with a capacity of 70 kg per day.
" For
Fitness studios /
smaller hotels /
smaller spas ice quantities of 70-150 kg per day are usually necessary.
"
Larger hotels /
Spas usually require ice output of 250 - 350 kg per day.
perfect ice for the sauna
Chip ice has the ideal temperature of
-0,5°Cwhich means that it never freezes together. The ice known as flake ice is available in different ice sizes (macro ice, micro ice, standard ice). The Fire and Ice ice fountain produces micro ice as standard, which, due to its small average size (
approx. 5mm) enables an extremely pleasant and fine cooling of the skin after sauna. Micro ice is also particularly suitable for use in the sauna, as it produces beautifully malleable
Ice balls which ensure even more effective infusions.
Hygiene of the ice fountain
Ice is considered drinking water and food even in the sauna - which is why our micro ice has the
Food approval under the conditions of the EU law. Furthermore, the ice fountain is equipped with an automatic residual water draining system, which in the event of a stop in ice production will automatically
Water drainage initiated. Thus, standing water is prevented when the ice machine stops and the risk of increased germ growth is bypassed. Bacteriological contamination is largely prevented by the design of the ice fountain (closed small water box, short pipes and closed ice cylinder). The high quality technology of the ice fountain with
closed water circuit thus supports any commercial wellness facility in complying with general and special hygiene regulations.
Cooling of the ice fountain / ice machine
Our ice fountains are available with water cooling or air cooling, the water cooled ice machine guarantees even at high ambient temperatures (as usual in sauna or wellness areas) a high performance and an almost noiseless ice production. Further advantages of the water-cooled ice maker are the easy installation (ready to connect to electricity and water) and the ambient air does not heat up
Guarantees of the ice fountain
Due to the production according to the highest quality standards (Made in Germany), the ice machine itself has a 2-year warranty. The spare parts for the ice fountain are guaranteed for at least 15 years guaranteed. The high quality parts (clean water pipes, evaporator surface and valves) also ensure an extremely high operational reliability and low maintenance and service costs.
additional hygiene options for water and ice machine
Below is a list of hygiene options for which we will be happy to provide you with an individual quotation:
-
Water filter: with activated carbon, coarse, fine filters and lime stabilizers to actively prevent the formation of a breeding ground for germs in the ice machine. Contributes to the preservation of machine performance and prolongation of its service life
-
UV disinfection: kills germs that could enter the machine through the water supply line before ice production.
-
HygienePlus rinsing function for all water-bearing parts
-
HygienePlus disinfection rinse for all water-bearing parts
-
Hygiene Set for water-bearing (and possibly calcified) parts. Easy to replace and cost-effective.
-
Special solutions for very high hygiene requirements
Installation instructions
The Fire and Ice ice fountain convinces by an extremely simple installation, which can be carried out by two specialists in 1-2 hours. In the assembly instructions, which explain safety instructions, delivery variants, services required on site, troubleshooting and maintenance, you will receive step-by-step instructions in pictorial form, which means that the ice fountain can always be assembled without any problems. Of course, we are always personally available to assist you and can also offer an installation service.
Download assembly instructions here:
